Limit the causes of excess consumption
Spread loads throughout the vehicle; place the heaviest items in the
bottom of the boot, as close as possible to the rear seats.
Limit the loads carried in the vehicle and reduce wind resistance (roof
bars, roof rack, bicycle carrier, trailer...). Use a roof box in preference.
Remove roof bars and roof racks after use.
At the end of winter, remove snow tyres and refit your summer tyres.
Observe the recommendations on
maintenance
Check the tyre pressures regularly, when cold, referring to the label in
the door aperture, driver's side.
Carry out this check in particular:
-
b
efore a long journey,
-
a
t each change of season,
-
a
fter a long period out of use.
Don't forget the spare wheel and the tyres on any trailer or caravan.
Have your vehicle serviced regularly (engine oil, oil filter, air filter,
passenger compartment filter...) and observe the schedule of
operations recommended in the manufacturer's service schedule.
With a BlueHDi Diesel engine, if the SCR system is faulty your vehicle
becomes polluting; go to a CITROËN dealer or a qualified workshop
without delay to have the emissions of nitrous oxides brought back to
the legal level.
When refuelling, do not continue after the third cut-off of the nozzle to
avoid any over flow.
At the wheel of your new vehicle, it is only after the first 1 800 miles
(3
000 kilometres) that you will see the fuel consumption settle down to
a consistent average.
.
Eco-driving
1 1 19 INSTRUMENTS and CONTROLS PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX INSTRUMENT PANELS Panel grouping together the vehicle operation indication dials and warning lamps. Depending on the version, the instrument panel may have permanent back-lighting. Indicates the speed of rotation of the engine (x 1 000 rpm). Citroen C4 PICASSO Description Description (36 pages) Citroen DS3 ULTRA PRESTIGE Brochure & Specs Brochure & specs (4 pages) CITROEN DS4 Owner's Handbook Manual Owner's handbook manual (396 pages) CITROEN C3 PICASSO User Manual Operation & user’s manual (2 pages) CITROEN CX Repair Manual Repair manual (394 pages). 230 C5: 2007 citroen component diagnosis technical training manual.pdf SID 803 / 803A EDC16C34 DOCUMENT REF N°: i.2.559 June 2007 AFTER SALES DIVISION The aim of this brochure is to present the features of the major sensor and actuators on the DV6TED4 and DW10BTED4 engines. Citroen 2004 c2 c3 c3 pluriel xsara & xsara picasso berlingo service workshop repair manual pdf download engine - injection - ignition - clutch, gearbox, driveshafts - axles, CITROEN C1, C2, C3, C3 PLURIEL 2005-2014, SERVICE, WORKSHOP. Citroen C3 Workshop, Owners, Service or Repair Manuals.
Page 12 of 292
10
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Petrol - Diesel instrument panel
Panel grouping together the digital indicator, the multifunction screen and the vehicle operation
indicator and warning lamps.
1.
R
ev counter.
I
ndicates the speed of rotation of the
engine (x 1000 rpm).
2.
R
ev counter zone indicating that you must
change up a gear.
3.
S
peed limiter
or
C
ruise control.
(
mph or km/h)
4.
E
lectric child lock indicator lamp.
I
ndicates, for a few seconds, the activation
of the electric child lock (deactivation of the
rear windows and doors).
Translucent digital instrument panel
This screen groups together the warning and
information messages.
Multifunction screen
Indicator lamps display zone
This zone groups together the vehicle
operation indicator lamps.
Display zero reset button
This permits resetting of the function selected
to zero (trip distance recorder or service
indicator).
Instrument panel lighting button
This adjusts the brightness of the lighting of the
instruments and controls.
5.
F
uel
gauge .
I
ndicates the quantity of fuel remaining in
the tank.
6.
S
peedometer
.
I
ndicates the current speed of the moving
vehicle (mph or km/h).
7.
T
rip distance recorder.
(
miles or km)
8. S
ervice indicator.
(
miles or km) then,
D
istance recorder.
(
miles or km)
9.
E
ngine oil level indicator. For more information, refer to the
paragraph relating to the button or
function and its associated display.
Monitoring
Page 13 of 292
11
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Indicator and warning lamps
Visual indicators informing the driver that a system is in operation (operation or deactivation indicator lamps) or of the occurrence of a fault (warning lamp).
Associated warnings
The illumination of certain warning lamps may
be accompanied by an audible signal and a
message in the multifunction screen.
The warning lamps may come on continuously
(fixed) or flash.
When the ignition is switched on
Certain warning lamps come on for a few
seconds when the vehicle's ignition is switched
on.
When the engine is started, these same
warning lamps should go off.
If they remain on, before moving off, refer to the
information on the warning lamp concerned.Certain warning lamps may come on
in one of two different modes. Only by
relating the type of illumination to the
operating status of the vehicle can it
be ascertained whether the situation is
normal or whether a fault has occurred.
Operation indicator lamps
If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.
Warning
/indicator lampis on Cause Action / Observations
Left-hand
direction indicatorflashing with buzzer.The lighting stalk is pushed down.
Right-hand
direction indicatorflashing with buzzer.The lighting stalk is pushed up.
Sidelamps fixed. The lighting stalk is in the
'Sidelamps' position.
Dipped beam
headlamps fixed.
The lighting stalk is in the 'Dipped
beam headlamps' position.
Main beam
headlamps fixed.
The lighting stalk is pulled towards you. Pull the stalk to return to dipped beam headlamps.
1
Monitoring
Page 14 of 292
Citroen C3 Picasso Manual
12
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Warning/indicator lampis on Cause Action / Observations
Front foglamps fixed. The front foglamps are switched on
using the ring on the lighting control
stalk. Turn the ring on the lighting control stalk rear ward
twice to switch off the front foglamps.
Rear foglamps fixed. The rear foglamps are on. Turn the ring on the stalk rear ward to switch off the
rear foglamps.
Diesel engine
pre-heating fixed.
The ignition switch is at the
2nd
position (ignition on).
Wait until the warning lamp has switched off before starting.
The duration for which the warning lamp is on is determined
by the climatic conditions.
Parking brakefixed. The parking brake is applied or not
properly released. Release the parking brake to switch off the warning
lamp, keeping your foot on the brake pedal.
Observe the safety recommendations.
For more information on the parking brake, refer to the
corresponding section.
Monitoring
Page 15 of 292
Citroen C4 Picasso
13
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Passenger
airbag systemfixed.The control switch, located at the
passenger's end of the dashboard, is in
the
'ON ' position.
The passenger's front airbag is activated.
In this case, do not install a rear ward
facing child seat on the front passenger
seat.Turn the control switch to the ' OFF' position to
deactivate the front passenger's airbag.
You can install a rear ward facing child seat on the
front passenger seat, except if there is a fault with the
airbags (airbag warning lamp on).
Warning
/indicator lampis on Cause Action / Observations
Electric child
lock temporarily.
The electric child lock is activated. Displayed for a few seconds after activating the
function and every time the ignition is switched on.
For more information, refer to the 'Child safety'
section.
1
Monitoring
Page 16 of 292
14
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Deactivation indicator lamps
Warning/indicator lampis on Cause Action / Observations
Passenger's
airbag system fixed.
The control switch, located at the
passenger's end of the dashboard, is
set to the 'OFF' position.
The passenger's front airbag is
deactivated.
You can install a rear ward facing
child seat on the front passenger
seat, except if there is a fault with the
airbags (airbag warning lamp on). Set the control switch to the 'ON'
position to activate
the passenger's front airbag. In this case, do not
install a child seat in the rear ward facing position.
If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally.
This is may be accompanied by an audible signal and a message in the multifunction screen.
Monitoring
Page 17 of 292
15
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Warning lamps
Warning/indicator lampis on Cause Action / Observations
STOP
fixed, alone or
associated with
another warning lamp,
accompanied by an
audible signal and a
message on the screen.The illumination of this warning lamp
is related to a serious fault with the
braking system, the power steering,
the engine oil pressure or the engine
coolant temperature. Stop as soon as it is safe to do so, as the engine may
cut out while driving.
Park, switch off the ignition and call a CITROËN
dealer or a qualified workshop.
Service temporarily,
accompanied by an
audible signal and
a message in the
multifunction screen. A minor fault has occurred for which
there is no specific warning lamp.
Identify the fault by reading the message shown in the
screen, such as, for example:
-
e
ngine oil level,
-
s
creenwash level,
-
r
emote control battery,
-
s
tate of the bulbs,
-
s
aturation of the particle filter on Diesel vehicles
(refer to the corresponding section).
For any other faults, contact a CITROËN dealer or a
qualified workshop.
fixed, accompanied
by an audible signal
and a message in the
multifunction screen. A major fault has occurred for which
there is no specific warning lamp.
Identify the fault by reading the message shown in the
screen and contact a CITROËN dealer or a qualified
workshop.
Any fault resulting in the illumination of a warning lamp must be investigated further by reading the
associated message in the multifunction screen.
If you encounter any problems, do not hesitate to contact a CITROËN dealer or a qualified workshop.When the engine is running or the vehicle is
being driven, the illumination of one of the
following warning lamps indicates a fault which
requires action on the part of the driver.
1
Monitoring
Page 18 of 292
16
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Warning/indicator lampis on Cause Action / Observations
Anti-lock
Braking System
(ABS) fixed.
The anti-lock braking system has a
fault. The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
CITROËN dealer or a qualified workshop without
d e l ay.
Dynamic
stability control
(DSC/ASR) flashing.
Regulation by the system is active. The system optimises traction and improves the
directional stability of the vehicle.
fixed, associated with
illumination of the indicator
lamp in the deactivation
button, accompanied by
an audible signal and a
message.The DSC/ASR or hill start assist
system has a fault.Have it checked by a CITROËN dealer or a qualified
workshop.
Engine
autodiagnosis
system flashing.
The engine management system has
a fault. Risk of destruction of the catalytic converter.
Have it checked by a CITROËN dealer or a qualified
workshop.
fixed. The emission control system has a
fault.
The warning lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or qualified
workshop without delay.
Brakingfixed, associated with
the STOP warning
lamp. The braking system fluid level is too
low.
You must stop as soon as it is safe to do so.
Top up with brake fluid recommended by CITROËN.
If the problem persists, have the system checked by a
CITROËN dealer or a qualified workshop.
+ fixed, associated with
the STOP and ABS
warning lamps.The electronic brake force distribution
(EBFD) system has a fault.
You must stop as soon as it is safe to do so.
Have it checked by a CITROËN dealer or a qualified
workshop.
Monitoring
Page 19 of 292
17
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Low fuel levelfixed. When it first comes on there remains
approximately 5 litres of fuel in the
tank. You must refuel as soon as possible to avoid running
out of fuel.
This warning lamp will come on every time the ignition
is switched on, until a sufficient addition of fuel is
made.
Fuel tank capacity: approximately 50 litres (petrol) or
48 litres (Diesel); depending on version: approximately
30 litres (petrol or Diesel).
Never continue to drive until you run out of fuel as
this could damage the emission control and injection
systems.
Warning
/indicator lampis on Cause Action / Observations
Maximum
coolant
temperature fixed.
The temperature of the cooling
system is too high. Stop as soon as it is safe to do so.
Wait until the engine has cooled down before topping
up the level, if necessary.
If the problem persists, contact a CITROËN dealer or
qualified workshop.
Engine oil
pressure fixed.
There is a fault with the engine
lubrication system. You must stop as soon it is safe to do so.
Park, switch off the ignition and contact a CITROËN
dealer or a qualified workshop.
Battery charge fixed. The battery charging circuit has a
fault (dirty or loose terminals, slack or
cut alternator belt, ...). The warning lamp should go off when the engine is
started.
If it does not go off, contact a CITROËN dealer or a
qualified workshop.
1
Monitoring
Page 20 of 292
18
C3Picasso_en_Chap01_controle-de-marche_ed01-2015
Warning/indicator lampis on Cause Action / Observations
Airbags temporarily. This lamp comes on for a few
seconds when you turn on the
ignition, then goes off. This lamp should go off when the engine is started.
If it does not go off, contact a CITROËN dealer or a
qualified workshop.
fixed. One of the airbag or seat belt
pretensioner systems has a fault. Have it checked by a CITROËN dealer or a qualified
workshop.
Front seat belt
not fastened /
unfastened fixed then flashing
accompanied by an
increasing audible
signal. The driver and/or the front passenger
has not fastened or has unfastened
their seat belt.
Pull the strap then insert the tongue in the buckle.
Rear seat belt
not fastened /
unfastened fixed then flashing
accompanied by an
audible signal. One or more rear passengers have
unfastened their seat belt.
Power steering fixed. The power steering has a fault. Drive carefully at reduced speed.
Have it checked by a CITROËN dealer or a qualified
workshop.
Door(s) open
fixed if the speed is
below 6 mph (10 km/h). A door or the boot is still open. Close the door or boot.
fixed and accompanied
by an audible signal
if the speed is above
6
mph (10 km/h).
Monitoring
